Specifikationer

SOUND GENERATOR    ORGAN SECTION:
2 Vase III as Digital Tone-Wheels, Transistor Organ and Pipe Organ
61 polyphony (for manual, except Pipe Organ)
8 polyphony (for pedal, except Pipe Organ)
63 polyphony (maximum, on Pipe Organ)
KEYBOARDS    C1 to C6 61-keys
HARMONIC DRAWBARS    DRAWBARS:
9 Ptiches, Assignable for Upper, Pedal, Lower
VOICING:
Manuals: 6 choices (B-Type1, B-Type2, Mellow, Vx, Farf, Pipe), Variable Key-click
Pedal: 4 choices (Normal, Muted, Synth1, Synth2), 5 choices Key-click
TOUCH RESPONSE PERCUSSION    BUTTONS:
Percussion On, Third Harmonic, Fast Decay, Volume Soft
ADJUSTABLE:
Touch, Velocity, Decay (Fast/Slow) Level (Normal/Soft)
EFFECTS    VIBRATO AND CHORUS:
Digital Scanner
Buttons: 1, 2, Chorus, Upper On, Lower On
OVERDRIVE:
Digital, 4 programs
Control: Amount
MULTI EFFECTS:
8 programs
EQUALIZER:
Bass, Mid, Treble, Tone
INTERNAL LESLIE©:
Advanced Digital, 2 Rotors
Buttons: Bypass, Stop, Fast
REVERB:
Digital, 11 programs
Control: On, Depth
Leslie On Reverb
MASTER EQUALIZER:
Bass, Mid, Treble
KEYMAP    BUTTONS:
Manual Bass, Split
ADJUSTABLE:
Coupler Highest note, Split Point, Octave Up for Lower, Octave Down for Lower, Transpose
PATCHES    CAPACITY:
64 User Patches, 64 Preset Patches, manual
FAVORITES:
8 buttons
PATCH LOAD OPTIONS:
Drawbar Registrations, Drawbar Parameters, Internal Zone, External Zone, Effects, Reverb
CONTROLLERS    VOLUMES:
Master Volume
SWITCH:
Power On/Off
STORAGE    USB Flash Drive
DISPLAY    20 Characters, 2 Lines
Control Buttons and Value knob
MIDI    TEMPLATES:
8 Templates
EXTERNAL ZONES:
3 Zones, assignable to any keyboard
CONNECTIONS    MIDI:
In, Out
AUDIO:
Line Out, L, R, Headphones
LESLIE©:
8-pin, 1 and 3 channels available
OTHER:
Foot Switch, Exp. Pedal, DC IN(12V)
ACCESSORY (INCLUDED)    AC Adaptor AD3-1250
DIMENSIONS    95,8cm(W) x 30,5cm(D) x 10,1cm(H)
WEIGHT    7.5Kg

Manual tilgængelig online: Engelsk, tysk, hollandsk og fransk
